HP Elite x2 G8 User Manual

Table 7-9 Issues, possible causes, and xes (continued)
Items Procedures
Tips Computer automatically boots without pressing power button when the RTC 3 V
battery is removed. Therefore, after the service door and RTC 3 V battery are removed,
you do not have to press power button from top side.
In essential hardware conguration, mWS G1 and G2 may require discrete graphics
processing unit (GPU) to boot. However, mWS G3 can boot with integrated graphics.
Intermittent power-on, shutdown, reboot
Use this information to troubleshoot power-on, shutdown, and reboot issues.
Table 7-10 Issues, possible causes, and xes
Items Procedures
Symptoms
● Does not always turn on
● Intermittently hangs
● Intermittently shuts down
● Spontaneously reboots
Possible causes
Electrical short, uctuating power source, unstable power rails, loose connections, bent pins,
stray wires, dust, obvious damage, nearly faulty parts (bulging or leaking capacitor).
Potentially turn into a no-power issue (No power on page 85).
Troubleshooting steps
1. Visually check power ports on both AC adapter and computer sides.
2. Inspect power sources:
a. Verify that the AC adapter is working correctly. Use a conrmed working adapter to
test.
b. Verify that battery is not depleted while system is in the Sleep state. Test with a
conrmed working battery.
The following steps are for authorized providers or technicians.
1. Follow actions in No power on page 85.
a. Be sure that AC adapter has correct DC voltage.
b.
Verify battery: test with a conrmed working battery.
c. Verify that power button is not stuck.
d. Verify that power connector is not loose.
e. Remedy loose connections and reseat major components (processor, memory, GPU,
hard drive, solid-state drive, and others).
2. Perform visual check for loose connections, bent pins, stray wires, dust, nearly faulty parts
(bulging or leaking capacitor).
3. Test essential hardware conguration (11. Test with minimum conguration on page 80)
a. If system boots, reinstall nonessential hardware one component at a time to isolate
issue.
b. If system does not boot, replace essential hardware with veried working parts, one
component at a time. If system still does not boot, replace system board.
Intermittent power-on, shutdown, reboot 87

HP Elite x2 G8 Specifications

General

Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
Market positioning	Premium
Original brand name	HP
HD type	3K2K
Color gamut	72 %
Display surface	Gloss
RGB color space	NTSC
Display diagonal	13 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	450 cd/m²
Display resolution	3000 x 2000 pixels
Display diagonal (metric)	33 cm
Numeric keypad	No
Pointing device	Clickpad
Internal memory	16 GB
Memory clock speed	4266 MHz
Memory form factor	On-board
Internal memory type	LPDDR4x-SDRAM
HP segment	Business
HP speaker type	HP Dual Speakers
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express
Storage media	SSD
SSD memory type	TLC
Total storage capacity	512 GB
Number of SSDs installed	1
Repairability index	8.4
Battery weight	190 g
Battery capacity	47 Wh
Number of battery cells	2
Discrete graphics card model	Not available
On-board graphics card model	Intel Iris Xe Graphics
Front camera HD type	Full HD
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
WLAN controller model	Intel Wi-Fi 6 AX201
WLAN controller manufacturer	Intel
Charging port type	USB Type-C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Processor cache	8 MB
Processor cores	4
Processor family	Intel® Core™ i5
Processor threads	8
Configurable TDP-up	28 W
Processor frequency	- GHz
Processor cache type	L3
Configurable TDP-down	12 W
Processor boost frequency	4.4 GHz
Configurable TDP-up frequency	2.6 GHz
Configurable TDP-down frequency	1.1 GHz
AC adapter power	65 W
Operating system installed	Windows 11 Pro
Package depth	483 mm
Package width	69 mm
Package height	305 mm

Weight and Dimensions

Depth	221.9 mm
Height	14.2 mm
Weight	1170 g
Depth (tablet mode)	215.8 mm
Width (tablet mode)	289.3 mm
Height (tablet mode)	8.8 mm
Weight (tablet mode)	820 g
