MSM410
Introduction
2-2
Introduction
This chapter shows you how to get started
using the
MSM410 (E-MSM410) Access Point.
Package contents
One MSM410 Access Point
One mounting brack
et
T
wo mounting screws (4 mm
x 25 mm (5/32 x 1 inch)) with wall a
nchors
T
wo T
-bar clip
s with four nuts (only provided
with rev B: US J9426B and WW J942
7B)
Documentation
The MSM410 is a W
i-Fi Alliance aut
horized W
i-Fi CERTIFIED 802.11a/b/g and
802.11n product. The W
i-Fi CERT
IFIED Logo is a certification mark of the W
i-Fi
Alliance.
