Left Rear Cover
The left rear cover is located on the left, rear of the computer. You must remove it to access the optical
drive and the hard drive.
To remove the left rear cover:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer on page 28).
2. Position the computer with the rear facing you.
3. Remove the small rear cover (see
Small Rear Cover on page 29).
4. Remove the stand (see
Stand on page 30).
5. Slide the cover toward the left and off the computer.
Figure 7-3 Removing the left rear cover
To replace the left rear cover, reverse the removal procedures.
Left Rear Cover
31
