Inverter Board
Description Spare part number
Inverter board 651601-001
The inverter board is located on the left side of the computer under the rear cover. It is secured with two
screws and has three connectors.
To remove the inverter board:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer on page 28).
2. Remove the small rear cover (see
Small Rear Cover on page 29).
3. Remove the stand (see
Stand on page 30).
4. Remove the right rear cover (see
Right Rear Cover on page 36).
5. Remove the heat sink (see
Heat Sink (Thermal Module) on page 39).
6.
Remove the rear cover (see
Rear Cover on page 47).
7. Disconnect the three cables from the board (1).
NOTE: Be careful not to damage the cables when disconnecting them from the board. Do not
pull on the wires.
Inverter Board
49
