Right Rear Cover
The right rear cover is located on the right, rear of the computer. You must remove it to access memory
and system board components.
To remove the right rear cover:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer on page 28).
2. Position the computer with the rear facing you.
3. Remove the small rear cover (see
Small Rear Cover on page 29).
4. Remove the stand (see
Stand on page 30).
5. Slide the cover toward the right and off the computer.
Figure 7-8 Removing the right rear cover
To replace the right rear cover, reverse the removal procedures.
36 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
