NOTE
Connect the black cable to the positive pole of the battery (+) and the blue cable to the negative pole (-).
AC Power
l Each AC power module is equipped with one AC power cable. Figure 4-80 shows the
appearance of an AC power cable.
Figure 4-80 AC power cable
l If a cabinet is equipped with PDUs, use PDU power cables to supply power to devices in
the cabinet. Figure 4-81 shows the appearance of a PDU power cable.
Figure 4-81 PDU power cable
4.9.2 Ground Cables
Ground cables are used for device grounding to improve the security when you perform
operations on a storage device.
Appearance
Figure 4-82 shows the appearance of a ground cable.
Figure 4-82 Ground cable
OceanStor 2600 V3
Product Description
4 Hardware Architecture
Issue 09 (2019-05-15) Copyright © Huawei Technologies Co., Ltd. 103
