Figure 4-62 System subrack
4.5.2.2 Expansion Module
Each expansion module provides two PRI HD expansion ports and two EXP HD expansion
ports. Expansion modules enable a high-density disk enclosure to communicate with a
controller enclosure or another high-density disk enclosure.
Appearance
Figure 4-63 shows the appearance of an expansion module.
Figure 4-63 Expansion module
OceanStor 2600 V3
Product Description
4 Hardware Architecture
Issue 09 (2019-05-15) Copyright © Huawei Technologies Co., Ltd. 79
