Huawei OceanStor 2600 V3 User Manual

Disk
No.
Slot
No.
Disk
No.
Slot
No.
Disk
No.
Slot
No.
Disk
No.
Slot
No.
Disk
No.
Slot
No.
1 A1 16 B1 31 C1 46 D1 61 E1
2 A2 17 B2 32 C2 47 D2 62 E2
3 A3 18 B3 33 C3 48 D3 63 E3
4 A4 19 B4 34 C4 49 D4 64 E4
5 A5 20 B5 35 C5 50 D5 65 E5
6 A6 21 B6 36 C6 51 D6 66 E6
7 A7 22 B7 37 C7 52 D7 67 E7
8 A8 23 B8 38 C8 53 D8 68 E8
9 A9 24 B9 39 C9 54 D9 69 E9
10 A10 25 B10 40 C10 55 D10 70 E10
11 A11 26 B11 41 C11 56 D11 71 E11
12 A12 27 B12 42 C12 57 D12 72 E12
13 A13 28 B13 43 C13 58 D13 73 E13
14 A14 29 B14 44 C14 59 D14 74 E14
4.5.2 Component Description
This section provides the detailed illustration and description for each component.
4.5.2.1 System Subrack
The system subrack houses a midplane to provide reliable connections for interface modules
and to distribute power and signals to inner modules.
Appearance
Figure 4-62 shows the appearance of a system subrack.
OceanStor 2600 V3
Product Description
4 Hardware Architecture
Issue 09 (2019-05-15) Copyright © Huawei Technologies Co., Ltd. 78
