Table 4-13 Indicators on an expansion module
No. Indicator Status and Description
3 Alarm indicator of the
expansion module
l Steady red: An alarm is generated in the
expansion module.
l Off: The expansion module is working
correctly.
4 Power indicator of the
expansion module
l Steady green: The expansion module is
powered on.
l Off: The expansion module is powered off.
5 Indicator of the mini
SAS HD expansion port
l Steady blue: Data is transferred to the
downstream disk enclosure at the rate of 4 x
12 Gbit/s.
l Steady green: Data is transferred to the
downstream disk enclosure at the rate of 4 x 3
Gbit/s or 4 x 6 Gbit/s.
l Steady red: The port is faulty.
l Off: The link to the port is down.
4.3.2.3 Power Module
The storage system supports AC and DC power modules. Power modules can ensure that the
disk enclosure works correctly in maximum power consumption mode.
Appearance
Figure 4-40 shows the appearance of an AC power module. Figure 4-41 shows the
appearance of a DC power module.
OceanStor 2600 V3
Product Description
4 Hardware Architecture
Issue 09 (2019-05-15) Copyright © Huawei Technologies Co., Ltd. 54
