Figure 5-4 Querying the health status for the RH2288 V3
d. Clear alarms. For details, see the Huawei Rack Server Alarm Handling (iBMC).
NOTE
If the query result in c indicates that no alarm is generated for the server, skip this step.
l Check the RH2288 V3 using the iBMC CLI.
a. Log in to the iBMC CLI.
i. Set an IP address for the PC, and ensure that the IP address is on the same
network segment as the iBMC management network port.
ii. Connect the PC to the RH2288 V3 iBMC management network port by using
a network cable.
iii. Run the Secure Shell (SSH) tool on the PC, and enter the IP address of the
iBMC management network port, user name, and password to log in.
NOTE
By default, SSH is used to log in to iBMC. If the SSH service is disabled, enable it by
choosing Config > Service Settings on the iBMC WebUI.
b. View the RH2288 V3 version information.
Check that the RH2288 V3 versions meet site requirements.
Hi1710 / # ipmcget -d v
------------------- iBMC INFO -------------------
IPMC CPU: Hi1710
IPMI Version: 2.0
CPLD Version: (U46)1.05
Active iBMC Version: (U25)1.26
Active iBMC Built: 08:26:05 Dec 23 2014
Backup iBMC Version: 1.26
SDK Version: 1.47
SDK Built: 08:28:02 Dec 19 2014
Active Uboot Version: 1.1.29 (Oct 13 2014 - 15:23:00)
Backup Uboot Version: 1.1.29 (Oct 13 2014 - 15:23:00)
----------------- Product INFO -----------------
Product ID: 0x0001
Product Name: RH2288
Product Version: V3
BIOS Version: (U47)1.19
-------------- Mother Board INFO ---------------
Mainboard BoardID: 0x000f
Mainboard PCB: .B
------------------- lexible NIC INFO -------------------
SM211 BoardID: 0x0017
SM211 PCB: .A
RH2288 V3 Server
User Guide
5 Configuring the RH2288 V3
Issue 32 (2019-03-28) Copyright © Huawei Technologies Co., Ltd. 106
