Procedure
Step 1 Wear an ESD wrist strap. For details, see 1 Safety Instructions.
Step 2 Determine the cabinet number and chassis number of the server to be removed, and label its
panel to prevent misoperations.
Step 3 Power off the RH2288 V3. For details, see 4.2 Powering Off the Server.
Step 4 Remove all external cables such as power and network cables.
Step 5 Remove the RH2288 V3 and put it on an ESD desktop. For details, see 3.6 Removing the
Server.
Step 6 Remove the chassis cover. For details, see 7.11 Removing the Chassis Cover.
Step 7 Pull up the right end of the system battery and remove it from the slot. See Figure 7-56.
Figure 7-56 Removing the system battery
Step 8 Place the removed system battery in an ESD bag.
----End
7.28 Installing the System Battery
Install a system battery to replace the original one.
RH2288 V3 Server
User Guide
7 Replacing Parts
Issue 32 (2019-03-28) Copyright © Huawei Technologies Co., Ltd. 178
