6 CONTROLS 17
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
– Fuel must not come into contact with the skin, eyes, or clothing. Do not breathe in the fuel vapors. If contact occurs with the
eyes, rinse with water immediately and contact a physician. Immediately clean contaminated areas on the skin with soap and
water. If fuel is swallowed, contact a physician immediately. Change clothing that is contaminated with fuel. Store fuel prop-
erly in a suitable canister and keep away from children.
Warning
Environmental hazard Improper handling of fuel is a danger to the environment.
– Do not allow fuel to get into the ground water, the ground, or the sewage system.
C00532-10
– Press release button
1
, turn filler cap counterclockwise and lift it upwards and
remove.
6.16 Closing filler cap
C00532-11
– Replace the filler cap and turn clockwise until the release button
1
locks in place.
Info
Route the fuel tank breather hose
2
without kinking.
6.17 Idle speed adjusting screw
C00533-10
The idle speed adjusting screw
1
is located on the throttle valve body at the top left.
The idle speed adjusting screw has two functions.
Turning it controls the idle speed.
Pulling it out all the way raises the idle speed during a cold start.
Possible states
• RPM increase activated – Idle speed adjusting screw is pulled out all the way.
• RPM increase deactivated – Idle speed adjusting screw is pushed in all the way.
