14 WHEELS, TIRES 74
14.1 Removing the front wheel x
Preparatory work
– Raise the motorcycle with a lift stand. ( p. 41)
L00215-10
Main work
– Press the brake caliper onto the brake disc by hand in order to push back the brake
pistons.
Info
Make sure when pushing back the brake pistons that you do not press the
brake caliper against the spokes.
L00212-10
– Loosen screw
1
by several turns.
– Release screws
2
.
– Press on screw
1
to push the wheel spindle out of the axle clamp.
– Remove screw
1
.
L00213-10
– Holding the front wheel, withdraw the wheel spindle. Take the front wheel out of the
fork.
Info
Do not pull the hand brake lever when the front wheel is removed.
Always lay the wheel down in such a way that the brake disc is not damaged.
L00214-10
– Remove spacers
3
.
14.2 Installing the front wheel x
Warning
Danger of accidents Reduced braking efficiency due to oil or grease on the brake discs.
– Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary.
L00214-11
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change the wheel bearing. x
– Clean and grease the shaft seal rings
1
and bearing surface
A
of the spacers.
– Insert the spacers.
