12
SERVICE
WORK
ON
THE
CHASSIS
52
12.28
Removing
the
manifold
x
Preparatory
work
–
Remove
the
seat.
(
p.
49)
–
Remove
the
right
side
cover.
(
p.
55)
–
Remove
the
main
silencer.
(
p.
54)
–
Raise
the
motorcyc
le
with
a
lift
stand.
(
p.
41)
309345-10
Main
work
–
Remove
fitting
1
.
–
Remove
screw
2
.
309346-10
–
Press
angle
lever
3
toward
the
rear.
–
Press
linkage
lever
4
downward.
309347-10
–
Raise
the
swingarm
.
309348-10
–
Remove
screw
5
.
–
Lower
the
shock
absorber.
53
55
