15 ELECTRICAL SYSTEM 85
15.12 Changing the speedometer battery
Preparatory work
– Switch off all power consumers and switch off the engine.
– Remove the headlight mask with the headlight. ( p. 82)
B01786-10
Main work
– Remove screws
1
.
– Pull the speedometer upward out of the holder.
B01644-10
– Using a coin, turn protection cap
2
all the way counterclockwise and remove it.
– Remove speedometer battery
3
.
– Insert the new battery with the label facing outward.
Speedometer battery (CR 2032) ( p. 105)
– Check the O-ring of the protection cap for correct seating.
B01645-10
– Position protection cap
2
and turn all the way clockwise using a coin.
– Press any button on the speedometer.
The speedometer is activated.
– Position the speedometer in the holder.
– Mount and tighten the screws with washers.
Finishing work
– Install the headlight mask with the headlight. ( p. 82)
– Check the headlight setting. ( p. 84)
– Set the speedometer. ( p. 20)
