ELECTRICAL SYSTEM 14
101
These battery chargers are only suitable for lithium
iron phosphate batteries. Read the accompanying
instructions for Husqvarna Motorcycles accessories.
Info
Never remove cover
1
.
– Switch off the battery charger after charging and disconnect
it from the 12-V battery.
Finishing work
– Install the 12-V battery. ( p. 99)
– Mount the seat. ( p. 63)
– Install the air filter box cover. ( p. 63)
14.4 Changing main fuse
Warning
Fire hazard Incorrect fuses overload the electrical system.
– Only use fuses with the required ampere value.
– Do not bypass or repair fuses.
Info
The main fuse protects all electrical power consumers of the vehicle. It is located in the starter relay
housing under the seat.
Preparatory work
– Remove the air filter box cover. ( p. 63)
– Remove the seat. ( p. 62)
V01612-10
Main work
–
Pull EFI control unit
1
upward off the rubber lugs
2
and
hang to the side.
–
Pull starter relay
3
from the holder.
