22 TECHNICAL DATA
136
Grease capacity, left cartridge 5 g (0.18 oz) Special grease (00062010053)
( p. 142)
Oil capacity, right cartridge 380 ml (12.85 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 140)
22.8 Shock absorber
Shock absorber article number 18.18.7U.73
Shock absorber WP XACT 5750
Lowspeed compression damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Highspeed compression damping
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload 7 mm (0.28 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 39 N/mm (223 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 42 N/mm (240 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 45 N/mm (257 lb/in)
Spring length 260 mm (10.24 in)
Gas pressure 10 bar (145 psi)
Static sag 35 mm (1.38 in)
Riding sag 105 mm (4.13 in)
Fitted length 477 mm (18.78 in)
Shock absorber fluid ( p. 140) SAE 2.5
22.9 Chassis tightening torques
Screw, air filter box EJOT PT
®
K70x25 5 Nm (3.7 lbf ft)
Screw, fuel pump EJOT PT
®
K60x25-Z 2.5 Nm (1.84 lbf ft)
Screw, intake air temperature sen-
sor
EJOTDELTA PT
®
45x12-Z 0.7 Nm (0.52 lbf ft)
Screw, oil fill level sensor G 3/4 " 7 Nm (5.2 lbf ft)
Screw, oil pump holder on oil tank EJOTDELTA PT
®
45x12-Z 0.7 Nm (0.52 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 2.3 Nm (1.7 lbf ft)
Screw, radiator hoses clip 2.4 Nm (1.77 lbf ft)
Screw, seat fixing EJOT EJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Fitting, stop button M3 0.4 Nm (0.3 lbf ft)
Screw cap, start button M3 0.4 Nm (0.3 lbf ft)
