22 TECHNICAL DATA
134
Screw, cylinder head temperature
sensor
M10x1.25 12 Nm (8.9 lbf ft)
Nut, rotor M12x1 60 Nm (44.3 lbf ft)
Gear oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
Spark plug M14x1.25 25 Nm (18.4 lbf ft)
Nut, inner clutch hub M18x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Nut, primary gear wheel M18LHx1.5 150 Nm (110.6 lbf ft)
Loctite
®
243™
22.3 Capacities
22.3.1 Gear oil
Gear oil 0.8 l (0.8 qt.) Engine oil (15W/50) ( p. 139)
22.3.2 Coolant
Coolant 1.2 l (1.3 qt.) Coolant ( p. 139)
22.3.3 Fuel
Total fuel tank capacity, approx. 8.5 l (2.25 US gal) Super unleaded (ROZ 95)
( p. 140)
Fuel reserve approx. 1.5 l (1.6 qt.)
2-stroke oil tank content approx. 0.6 l (0.6 qt.) Engine oil, 2-stroke ( p. 139)
22.4 Chassis
Frame Central tube frame made of chrome molybdenum
steel tubing
Fork WP XACT 5448
Suspension travel
front 310 mm (12.2 in)
rear 300 mm (11.81 in)
Fork offset 22 mm (0.87 in)
Shock absorber WP XACT 5750
Brake system Disc brakes, floating brake calipers
Brake discs - diameter
front 260 mm (10.24 in)
rear 220 mm (8.66 in)
Brake discs - wear limit
front 2.5 mm (0.098 in)
rear 3.5 mm (0.138 in)
Offroad tire pressure
front 1.0 bar (15 psi)
rear 1.0 bar (15 psi)
Secondary ratio 13:51
