17 SERVICE WORK ON THE ENGINE
118
V01624-10
–
Check whether air bubbles are visible in the hose
7
.
» If air bubbles are visible:
– Repeat the entire procedure until air bubbles are no
longer visible.
– Mount protection cap on the diagnostics connector.
– Mount the EFI control unit on the rubber lugs.
Finishing work
– Mount the seat. ( p. 63)
– Install the air filter box cover. ( p. 63)
17.4 Cleaning the oil screen in the oil tank
Note
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance
with the applicable regulations.
Preparatory work
– Remove main silencer. ( p. 66)
– Remove the air filter box cover. ( p. 63)
– Remove the seat. ( p. 62)
– Remove the right side cover. ( p. 67)
– Remove the fuel tank. ( p. 68)
– Raise the motorcycle with a lift stand. ( p. 49)
V01627-10
Main work
–
Remove screws
1
.
–
Loosen screws
2
.
