HyPrecision 50S/60S/75S Operator Manual 808690 175
8 – Pump specifications
Pump specifications
HyPrecision 50S
Dimensions and weights
The shipping weight is for the pump, the pallet, and the packaging. Exact weights are taken at shipment.
Operating weight is for an unpackaged pump with hydraulic fluid.
Width 1,016 mm (40 in.) Shipping weight 1,324 kg (2,920 lb)
Length 1,930 mm (76 in.) Operating weight 1,406 kg (3,100 lb)
Height 1,422 mm (56 in.)
37 kW, 50 hp
50 Hz 60 Hz
Voltage 400V 208V to230V 460V
Full-load current 72.4 A 138.0 A to 126.0 A 62.0 A
Primary circuit breaker rating 80.0A150.0A80.0A
50 Hz 60 Hz
CUTTING WATER IN Minimum Maximum
Flow
7.6 L/minute
(2 gallons/minute)
—
Pressure
2.76 bar or 275.79 kPa
(40 psi)
7.93 bar or 792.90 kPa
(115 psi)
CUTTING WATER OUT
Flow
—
3.8 L/minute
(1 gallon/minute)
4.1 L/minute
(1.07 gallons/minute)
Pressure
551.58 bar or 55,158 kPa
(8,000 psi)
4,136.85 bar or 413,685 kPa
(60,000 psi)
Continuous pressure
—
4,136.85 bar or 413,685 kPa
(60,000 psi)
Cutting water pressure
factory setpoint
—
4,137 bar or 413,685 kPa
(60,000 psi)
Piercing water pressure
factory setpoint
1379 bar or
137,895 kPa
(20,000 psi)
—
COOLING IN and COOLING OUT
Flow
11.4 L/minute
(3 gallons/minute)
—
Pressure
2.76 bar or 275.79 kPa
(40 psi)
7.93 bar or 792.90 kPa
(115 psi)
