HyPrecision 50S/60S/75S Operator Manual 808690 191
9 – Installation
Installation
Make the connections for remote operation
Remote operation is optional.
All controls are 24-volt direct current (VDC).
These tables show the remote connections from a user panel or a computer numerical control (CNC) operator
console. Refer to
Operate the pump remotely on page 66 for details about these controls.
Remote emergency stop
The OEM or the system integrator is responsible for connecting the emergency stop.
The terminals are in series with the emergency stop circuit. The terminals are wired to dry contacts on the
emergency stop at the remote control source.
If the pump is set up to run remotely and has a motion system (robot or cutting table), the emergency circuits from
the robot or cutting table can be in series with the local emergency stop circuit.
Remote controls on
If the pump is off, this turns on the primary control relay.
Wire number Type of contact
Operation
5024A Normally closed
Status
5024A Normally closed
Discrete pressure input
6022, 6022A Input, maintained, normally open
Remote mode active indicator
6027, 24COM Output
Remote pump fault indicator
7004, 24COM Output
Remote pump run indicator
6047, 24COM Output
Controls on indicator
5024C Output
Wire number Type of contact
Operation
6027, 5024A Momentary, normally open
Status
6027, 5024A Momentary, normally open
