Removals and Replacements—Machine Type 2134
See Safety Notice 1: Translation on page xi
Before removing any FRU, power-off the computer, unplug all power
cords from electrical outlets, then disconnect any interconnecting cables.
Attention: The system board, processors, adapter cards, SIMMs, DIMM,
and upgrade processors can be damaged by electrostatic discharge. Use an
electrostatic discharge (ESD) strap to establish personal grounding. If you
don’t have an ESD strap, establish personal grounding by touching a ground
point with one hand before touching the static-sensitive FRUs.
The arrows in the removals and replacements procedures show the direction
of movement to remove a field-replaceable unit (FRU), to turn a screw, or to
press a tab to release the FRU.
Begin all removals by removing the cover (and rear cover, if applicable).
When other FRUs must be removed prior to removing the failing FRU, they
are listed at the top of the page. Go to the removal procedure for each FRU
listed, remove the FRU, and then continue with the removal of the failing
FRU.
To replace a FRU, reverse the removal procedure and follow any notes that
pertain to replacement. See “Parts/Test Point Locations” on page 5-1 for
internal cable connections.
Before disconnecting any cables, note their locations. Reinstall any new
FRUs with cables in the same locations.
4-2
