2080—Lithium Battery
Adapter cards (2035) if applicable.
Riser card (2045).
Insert the tip of a screwdriver (1) under the clip and raise the clip (2)
carefully to remove the battery.
See Safety Notice 2: Translation on page xii
The lithium battery can cause a fire, explosion, or severe burn. Do not
recharge it, remove its polarized connector, disassemble it, heat it above
100°C (212°F), incinerate it, or expose its cell contents to water.
Dispose of the battery as required by local ordinances or regulations.
Use only the battery in the appropriate parts listing. Use of an incorrect
battery can result in ignition or explosion of the battery.
Attention: Be careful when removing the battery. If the retaining clip is
broken, the system board must be replaced.
Note: Run the Setup Utility after installing a battery.
1
2
Battery
Retaining
Clip
Figure 4-36. Lithium Battery
Repair Information 4-35
