Sound Card
MIC
Line In
Line Out Game/Midi
Connector
JP2
JP4
JP5
JP1/JP2 Connection
Between Main and Daughter Cards
Daughter Card
Figure 5-13. Sound Card
Sound Card Connectors
Table 5-1. Sound Card Connectors
Connector Description
JP2 CD-ROM connector
JP4 Video Conference connector
JP5 TV Connector
5-14
