EMEA Mwave Jumpers and Connectors
P3 (CD-ROM1)
P4, P5 (I/O Address):
P4 and P5 are jumpered to I/O address CE3O. The
I/O jumper setting can be changed to correct conflicts with other cards using
I/O addresses or Joystick port settings.
Short the top pin to middle pin for jumper position A.
Short the bottom pin to middle pin for jumper position B.
P7 (Wake Up On Ring)
P8 (Unused)
P9 (Unused)
P10 (Joystick Enable/Disable)
Short P10 to enable the Joystick.
Open P10 to disable the Joystick
To Select I/O Address: Set P4 to: Set P5 to:
CE30 Position B Position B
01B0 Position A Position B
0130 Position A Position A
Parts/Test Point Locations 5-13
