2090—System Board
Adapter cards (2035) if applicable.
Riser card (2045).
Disconnect any cables necessary for removal.
Memory (SIMM) (2050) if applicable.
Cache memory (2055) if applicable.
Processor (2060).
Notes:
1. Be certain to reinstall the processor, SIMMs, and cache memory in the
new system board if applicable.
2. When reinstalling a new system board, push the board to the rear and
place it over the front locating pin prior to installing the screws.
3. Run the Setup Utility after changing the system board.
Repair Information 4-37
