2
1. ADVANCED CONNECTIONS
To the USB
port
USB cable
(supplied with the RC-28)
RC-28
Connecting the RC-28
The optional RC-28 remote encoder can be used as
a sub dial.
NOTE:
•
RS-BA1 ip remote control software.
• Using the RC-28 with other than the USB cable
supplied with the RC-28, or connecting it through a
USB hub, is not guaranteed by Icom.
D Using the RC-28
[TRANSMIT] LED
Lights while transmitting.
[LINK] LED
Lights while the RC-28 is connected to
the transceiver.
Main dial
frequency (with the default setting).
[F-1]/[F-2] LEDs*
[F1] lights when operating the Main band,
and [F-2] lights when operating the Sub
band.
[F-1]/[F-2] buttons*
Selects the Main band or Sub band to
operate with the main dial.
[TRANSMIT] button
Push to switch between transmit and
receive.
* The [F-1] and [F-2] buttons or keys are disabled
L Setting the “USB Dial Select” to “MAIN/SUB”
enables you to operate both the Main band and the
Sub band, using the RC-28.
» SET > Connectors > USB DIAL >
USB DIAL SELECT
