71
8. SCANS
∂F scan
∂F scan and Fine ∂F scan
Scan Scan
14.18 MHz 14.19 MHz14.17 MHz
(Example: Span: ±10 kHz)
Start
CenterScan edge Scan edge
Jump
Repeatedly scans within the ∂F span area.
The scan starts from the center frequency.
L∂F), the scan
speed decreases when the squelch opens, but
the transceiver keeps scanning. The scan tuning
step changes to 10 Hz when the squelch opens.
D ∂F scan operation
1. In the Main band, set the center frequency.
(Example: in the VFO mode)
2. Set the operating mode and the tuning step.
(Example: USB, 1 kHz)
LYou can also change these settings while scanning.
3. Display the SCAN screen.
» SCAN
4. Touch [∂F SPAN] to select the span.
• Options: ±5 kHz, ±10 kHz, ±20 kHz, ±50 kHz,
±100 kHz, ±500 kHz, or ±1 MHz
5. Touch [∂F] to start the scan.
L When a signal is detected, the scan pauses
according to the “SCAN Resume” setting, and then
resumes.
LTo cancel the scan, touch [
∂F] again.
L To turn the TS function to scan by the frequency step
setting, touch the 100 kHz digit on the frequency
readout.
Blinks
The frequency
before starting the scan
The span set in step 4
6. To switch to the Fine ∂F scan, touch [FINE].
• The scan frequency step changes to 50 Hz.
L Touching [FINE] switches between the ∂F scan and
the Fine ∂F scan.
7. To close the SCAN screen, push
.
Blinks
To Next Page
