Icom ID-51A User Manual

16
MENU SCREEN
16-78
■ Function items (Continued)
CI-V (DATA Jack) (Default: OFF)
Function > CI-V > CI-V (DATA Jack)
Selects whether or not to use the [DATA] jack to remotely control the transceiver.
• OFF: Do not use the [DATA] jack to remotely control the
transceiver.
• ON (Echo Back OFF): Use the [DATA] jack to remotely control the trans-
ceiver.
- Does not send back the CI-V command input from
the [DATA] jack.
• ON (Echo Back ON): Use the [DATA] jack to remotely control the trans-
ceiver.
- Sends back the CI-V command input from the
[DATA] jack.
TIP: When you use the optional RS-MS1A, select “ON (Echo Back OFF).”
CI-V Address (Default: 86)
Function > CI-V > CI-V Address
To distinguish equipment, each CI-V transceiver has its own Icom standard
address in hexadecimal code.
The ID-51A/E’s default address is 86.
When 2 or more ID-51A/Es are controlled through a PC at the same time,
set a different address for each device between 01h and DFh (hexadecimal).
CI-V Baud Rate (Default: Auto)
Function > CI-V > CI-V Baud Rate
Set the CI-V data transfer speed to 300, 1200, 4800, 9600, 19200 bps or
Auto.
When “Auto” is selected, the baud rate is automatically set according to the
data rate of the controller.
NOTE:
You can select “300 bps,” “1200bps,” or “Auto” only when “CI-V (DATA
Jack)” (p. 16-78) is set to “OFF.”
CI-V Transceive (Default: OFF)
Function > CI-V > CI-V Transceive
Turn the CI-V Transceive function ON or OFF.
• OFF: Turns the function OFF.
• ON: When you change a setting on the transceiver, the same change is
automatically set on other connected transceivers or receivers, and
vice versa.
TIP: When you use the optional RS-MS1A, select “ON.”
