Tiny Modbus/TCP to RTU/ASCII Gateway
Copyright © 2020 ICP DAS CO., Ltd. All Rights Reserved. - 100 -
7.2 Exception Codes
If an exception occurs during Modbus communication, the slave device will return an Exception
Code in the response message. The following is an explanation of the Exception Codes:
Exception Codes:
Indicates that the function code received in the query is not an allowable action for the slave. If not an
allowable action for the slave. If a Poll Program Complete command was issued, this code indicates that
no program function preceded it.
Indicates that the data address received in the query is not an allowable address for the slave.
Indicates that a value contained in the query data field is not an allowable value for the slave.
Indicates that an unrecoverable error occurred while the slave was attempting to perform the requested
action.
Indicates that the slave has accepted the request and is processing it, but it will take an extended period of
time to do so. This response is returned to prevent a timeout error from occurring in the master. The
master can issue a Poll Program Complete message later to determine whether the processing is
complete.
Indicates that the slave is engaged in processing a long–duration program command. The master should
retransmit the message later when the slave is free.
Indicates that the extended file area failed to pass a consistency check, and the slave cannot perform the
program function received in the query. This code is returned when a programming request using function
code 13 or 14 decimal was unsuccessful. The master should request diagnostic or error information from
the slave.
Indicates that the slave attempted to read extended memory, but detected a parity error in the memory.
The master can retransmit the request, but maintenance may be required on the slave device.
