ICP DAS USA tGw-735 User Manual

Tiny Modbus/TCP to RTU/ASCII Gateway
Copyright © 2020 ICP DAS CO., Ltd. All Rights Reserved. - 23 -
tGW-725/tGW-725i
tGW-735/tGW-735i
tGW-725
tGW-725i
Terminal No.
Pin Assignment
10
F.G.
F.G.
09
N/A
N/A
08
N/A
N/A
07
N/A
N/A
COM2
06
GND
ISO.GND
05
D2-
D2-
04
D2+
D2+
COM1
03
GND
ISO.GND
02
D1-
D1-
01
D1+
D1+
tGW-735
tGW-735i
Terminal No.
Pin Assignment
10
F.G.
F.G.
COM3
09
GND
ISO.GND
08
D3-
D3-
07
D3+
D3+
COM2
06
GND
ISO.GND
05
D2-
D2-
04
D2+
D2+
COM1
03
GND
ISO.GND
02
D1-
D1-
01
D1+
D1+
