Tiny Modbus/TCP to RTU/ASCII Gateway
Copyright © 2020 ICP DAS CO., Ltd. All Rights Reserved. - 13 -
2.2 Appearance
tGW-700 Series
tGW-700-T Series
5. Serial COM Ports
4. LED indicator
3. Operating Mode
Switch
2. +12 to +48 V
DC
Jack
1. PoE and Ethernet
RJ-45 Jack
6. DIN-Rail Mounting
5. Serial COM Ports
4. LED indicator
3. Operating Mode
Switch
2. +12 to +48 V
DC
Jack
1. Ethernet RJ-45 Jack
6. DIN-Rail Mounting
