Tiny Modbus/TCP to RTU/ASCII Gateway
Copyright © 2020 ICP DAS CO., Ltd. All Rights Reserved. - 34 -
3.2 Configuring Network Settings
1. Downloaded the eSearch Utility and installed according to the
installation instructions.
The eSearch Utility can be obtained from the ICP DAS web site.
The location of the download addresses is shown below:
http://www.icpdas.com/en/product/guide+Software+Utility_Driver+eSearch__Utility
2. Double click the eSearch Utility shortcut on the desktop.
3. Click the “Search Servers” button to search your tGW-700/GW-2200.
4. Once the search process is complete, double-click the name of the tGW-700/GW-2200 to open
the “Configure Server” dialog box.
To Next Page
