Chapter 2: Installation
16 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
The intrusion control panel is only allowed to be serviced by dedicated service
personal. The screw of the housing is intended to protect the product from
unintended use.
For metal housing, the screw is already installed out of the box. For plastic
housing, the screw, available inside housing, should be mounted before first time
use.
Use the mains connector terminal for connecting the AC mains supply. A fixed
cable or flexible mains lead to earthed mains outlet can be used. When fixed
wiring is used, insert a dedicated circuit breaker in the power distribution network.
In all cases the mains connection must comply with local regulations.
In case the panel is connected to the power grid using fixed wiring, it is
recommended that earth wire is longer than line and neutral.
Do connect incoming line and neutral to mains connection block according to the
label. This assures that the line will be protected by the mains fuse, and that
service can be done by service personnel.
Make sure that before connecting the mains power, the mains power supply is
disconnected.
When installing the mains power, use strain reliefs such as cable ties and
coupling PG16s to ensure proper wiring. If product entry hole breakouts are
used, it is required to also make use of UL-V2 (or better) approved PG16 cable
gland. Refer to PG16 specification to meet minimum and maximum cable
diameters.
In all cases local regulations must be observed.
WARNING: Electrocution hazard. To avoid personal injury or death from
electrocution, remove all sources of power and allow stored energy to discharge
before installing or removing equipment.
Battery replacement
This product may contain one (or more) sealed, rechargeable, BS-type lead-acid
battery. Because removing a battery may affect the product’s configuration
settings or trigger an alarm, only a qualified installer should remove the batteries.
To remove a battery:
1. Make sure that your product settings allow you to open the cover without
starting the tamper alarm.
2. Switch off the mains power, if necessary, and remove the cover.
