Chapter 2: Installation
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 35
Specifications
For a list of panel models see “List of panel variants” on page iii.
Mains power specifications
Mains input voltage
230 VAC +10%, −15%, 50 Hz 10%
Current consumption at 230 VAC:
ATS1500A(-IP)
300 mA max.
ATS3500A(-IP), ATS4500A-IP
500 mA max.
Transformer output:
ATS1500A(-IP)-SM/LP
20 VAC, 31 VA
ATSx500A(-IP)-MM/MM+/LM
23 VAC, 58 VA
ATS3500A(-IP)-LP
22 VAC, 53 VA
Power supply specifications
Power supply type
Type A per EN 50131-6
Type I per VdS 2115
Power supply voltage [1]
13.8 V 0.2 V
Power supply current:
ATS1500A(-IP)
1.10 A max. at 13.8 V 0.2 V
ATS3500A(-IP)
2.10 A max. at 13.8 V 0.2 V
ATS4500A-IP
2.65 A max. at 13.8 V 0.2 V
Main board consumption:
ATSx500A
100 mA at 13.8 V ±0.2 V
ATSx500A-IP
150 mA at 13.8 V ±0.2 V
Maximum system current available [2]:
ATS1500A
1000 mA at 13.8 V ±0.2 V
ATS1500A-IP
950 mA at 13.8 V ±0.2 V
ATS3500A
2000 mA at 13.8 V ±0.2 V
ATS3500A-IP
1950 mA at 13.8 V ±0.2 V
ATS4500A-IP
2500 mA at 13.8 V ±0.2 V
Auxiliary power output (AUX. POWER) [3]
13.8 V 0.2 V, 1 A max.
Battery power output (BAT) [4]
13.8 V 0.2 V, 2.5 A max.
Battery type
Lead acid rechargeable: [5]
7.2 Ah, 12 V nom. (BS127N)
12 Ah, 12 V nom. (BS130N)
18 Ah, 12 V nom. (BS131N)
26 Ah, 12 V nom. (BS129N)
36 Ah, 12 V nom. (BS134N)
