INVT CHE100-0R7G-S2 User Manual

List of Function Parameters
101
Function
Code
Name Description
Factory
Setting
Modify
P4.00
V/F curve selection
0:Linear curve
1: User-defined curve
2: Torque_stepdown curve (1.3 order)
3: Torque_stepdown curve (1.7 order)
4: Torque_stepdown curve (2.0 order)
0

P4.03 V/F frequency 1 0.0Hz ~ P4.05 100.0Hz O
P4.04 V/F voltage 1 0.0% ~ 100.0% (motor rated voltage) 10.0%

P4.05 V/F frequency 2 P4.03 ~ P4.07 600.0Hz O
P4.06 V/F voltage 2 0.0% ~ 100.0% (motor rated voltage) 60.0%

P4.07 V/F frequency 3 P4.05 ~ P2.02 (motor rated frequency) 1000.0Hz O
P4.08 V/F voltage 3 0.0% ~ 100.0% (motor rated voltage) 100.0%

P4.09
V/F Slip compensation
limit
0.00~200.0%
0.0% O
P4.10
Auto energy saving
selection
0: Disabled
1: Enabled
0

Parameters display on LCD keypad
Function Code Name LCD Display
P0.00 Control mode selection CONTROL MODE
P0.01 Run command source RUN COMMAND
P0.02 UP/DOWN setting UP/DOWN SETTING
P0.03 Frequency A command source FREQ SOURCE A
P0.04 Maximum frequency MAX FREQ
P0.05 Upper frequency limit UP FREQ LIMIT
P0.06 Lower frequency limit LOW FREQ LIMIT
P0.07 Keypad reference frequency KEYPAD REF FREQ
P0.08 Acceleration time 0 ACC TIME 0
P0.09 Deceleration time 0 DEC TIME 0
P0.10 Running direction selection RUN DIRECTION
P0.11 Carrier frequency CARRIER FREQ
