INVT CHE100-0R7G-S2 User Manual

Detailed Function Description
64
P7.19
Output
terminal status
at current fault
This value records output terminal
status at current fault. The
meaning of each bit is as below:
BIT3 BIT2 BIT1 BIT0
RO Y
1 indicates corresponding output
terminal is ON, while 0 indicates
OFF. Notice: This value is
displayed as decimal.
6.9 P8 Group--Enhanced Function
Function
Code
Name Description Setting Range
Factory
Setting
P8.00
Acceleration time 1
1.0~3600.0s
1.0~3600.0 20.0s
P8.01
Deceleration time 1
1.0~3600.0s
1.0~3600.0 20.0s
For details, please refer to description of P0.08 and P0.09.
Function
Code
Name Description Setting Range
Factory
Setting
P8.02 Jog reference 0.00~P0.04 0.00~ P0.04 5.00Hz
P8.03 Jog acceleration time 0.1~3600.0s 0.1~3600.0
Depend
on model
P8.04 Jog deceleration time 0.1~3600.0s 0.1~3600.0
Depend
on model
The meaning and factory setting of P8.03 and P8.04 is the same as P0.08 and P0.09. No
matter what the value of P1.00 and P1.05 are, jog will start as start directly mode and stop
as deceleration to stop mode.
Function
Code
Name Description Setting Range
Factory
Setting
P8.05 Skip frequency 0.00~P0.04 0.00~P0.04 0.00Hz
P8.06
Skip frequency
bandwidth
0.00~P0.04 0.00~P0.04 0.00Hz
By means of setting skip frequency, the inverter can keep away from the mechanical
resonance with the load. P8.05 is centre value of frequency to be skipped.
Notice:
 If P8.06 is 0, the skip function is invalid.
 If P8.05 is 0, the skip function is invalid no matter what P8.06 is.
 Operation is prohibited within the skip frequency bandwidth, but changes
