INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Extension cards
-446-
Appendix A Extension cards
A.1 Model description
EC-PG 5 01-05
① ② ③ ④ ⑤
Field
Description
Example
①
Product category
EC: Extension card
②
Card category
PG: PG card
③
Technical version
Indicates the generation of a technical version by
using odd numbers, for example, 1, 3, and 5
indicate the 1
st
, 2
nd
, and 3
rd
generations of the
technical version.
④
Distinguishing code
01: Incremental PG card + Frequency-division
output
02: Sine/Cosine PG card + Pulse direction setting +
Frequency-division output
03: UVW PG interface + Pulse direction setting +
Frequency-division output
04: Resolver PG interface + Pulse direction setting
+ Frequency-division output
05: Incremental PG card + Pulse direction setting +
Frequency-division output
06: Absolute PG interface + Pulse direction setting
+ Frequency-division output
07: Simplified incremental PG card
⑤
Working power
00: Passive
05: 5V
12: 12–15 V
24: 24 V
