INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Commissioning
- 61 -
5.8 Commissioning winching in open-loop vector control (applicable to lifting
in mineral wells and winches)
5.8.1 Wiring
(+) PB
GD350-19 VFD
R
S
T
R
S
T
M
3~
U
V
W
PE
S1
S2
S3
S4
Brake
output
VFD fault
output
RO1A
RO1B
RO1C
RO2A
RO2C
FWD running
REV running
Fault reset
Braking resistor
COM
Upward position limit
RO2B
GND
AI1
+10V
PW
+24V
Figure 5.9 Wiring for winching in open-loop vector control (recommended analog reference 0V–10V)
(+) PB
GD350-19 VFD
R
S
T
R
S
T
M
3~
U
V
W
PE
S1
S2
S3
S4
Brake
output
VFD fault
output
RO1A
RO1B
RO1C
RO2A
RO2C
FWD running
REV running
Fault reset
Braking resistor
COM
Upward position limit
RO2B
-10V (externally
connected)
AI2
+10V
PW
+24V
Figure 5.10 Wiring for winching in open-loop vector control (using analog reference -10V–10V)
Note: If the onsite function terminals are inconsistent with the terminals shown in the wiring diagrams,
select the open-loop vector controlled winching function macro and adjust the input and output
