INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Dimensional drawings
-494-
C.5 AC 3PH 380V(-15%)–440V(+10%) VFD dimensions
C.5.1 Wall-mounting dimensions
W1
H1
D1 W2
H2
Figure C.6 380V 1.5–37kW VFD wall mounting diagram
VFD model
Outline dimensions
(mm)
Hole distance
(mm)
Hole
diameter
(mm)
Screw
Net
weight
(kg)
Gross
weight
(kg)
W1
H1
D1
W2
H2
1.5kW–2.2kW
126
186
185
115
175
5
M4
2
3
4kW–5.5kW
126
186
201
115
175
5
M4
2.5
3.5
7.5kW
146
256
192
131
243.5
6
M5
3
4
11kW–15kW
170
320
220
151
303.5
6
M5
6
7
18.5kW–22kW
200
340.6
208
185
328.6
6
M5
8.5
10.5
30kW–37kW
250
400
223
230
380
6
M5
16
17
