INVT Goodrive350-19 Series User Manual

Goodrive350-19 series VFD Dimensional drawings
-492-
Keypad installation bracket Installation dimensions
Figure C.2 (Standard) Installation bracket for 380V 37–315kW and 660V 22–630kW models
C.3 LCD keypad
C.3.1 Structural diagram
Opening sizes for installing the keypad without a bracket
Keypad outline
2
- M
3
*
8
Tapping
screw
Panel
Keypad
109.3
71.3
28.5
16.8
2.5
109.3
56
6.7
71.3
58
2- ø4
1934.4
19
20.4
Figure C.3 Keypad structure
C.3.2 Keypad installation bracket
Note: You can directly use M3 threaded screws or an installation bracket to externally connect the
keypad to the VFD. The installation bracket is optional for 380V 1.5–30 75 VFD models. The
installation bracket is also optional for 380V 90–500 kW VFD models and 660V 22–630kW VFD
models but the keypads for these models can be externally mounted.
