INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Product overview
‐3‐
Function difference between different machine types:
Small power range: 100W-5.5kW
Drive type Symbol
Pulse
input
16-bit
analog
input
2
nd
encoder
STO
RS48
5
CAN
open
PROFI
BUS-
DP
Ether
CAT
Motion
Net
Photoelectri
c encoder
Rotary
transfor
mer
Pulse type
E0 ○ × ○ × ○ × × × × ○ ×
E7 ○ × ○ × ○ × × × × × ○
Standard
type
S0 ○ ○ ○ ○ ○ × × × × ○ ×
S7 ○ ○ ○ ○ ○ × × × × × ○
Bus type
C0 × × ○ × × ○ × × × ○ ×
P0 × × ○ × × × ○ × × ○ ×
N0 × × ○ × × × × ○ × ○ ×
M0 × × ○ × ○ × × × ○ ○ ×
Customized
K0 ○ × ○ × ○ ○ × × × ○ ×
K7 ○ × ○ × ○ ○ × × × × ○
Medium-power range: 7.5kW-22kW
Drive type Symbol
Pulse
input
16-bit
analog
input
2
nd
encoder
STO
RS48
5
CAN
open
PROF
IBUS-
DP
Ether
CAT
Motion
Net
Photoelectri
c encoder
Rotary
transfor
mer
Standard
type
S0 ○ ○ ○ ○ ○ ○ × × × ○ ×
S7 ○ ○ ○ ○ ○ ○ × × × × ○
Bus type
N0 × × ○ ○ × × × ○ × ○ ×
N7 × × ○ ○ × × × ○ × × ○
Customized
K0 ○ × ○ ○ ○ ○ × × × ○ ×
K7 ○ × ○ ○ ○ ○ × × × × ○
Note: In above table, “○” means this function is available, “×” means this function is unavailable.
1.1.4 Name plate of the drive
S/N:
3P AC 0V ~ V in 0 ~ 400Hz 2.8A 400W
1P/3P AC 220V(-15%) ~ 240V(+10%) 47 ~ 63Hz 3.6A/1.5A
伺服驱动器
型 号：
输 入
INPUT
输 出
OUTPUT
SERVO DRIVES
MODEL：
SV-DA200-0R4-2-E0


