INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Product overview
‐4‐
1.1.5 Power ratings and cabinet volumes
Model
Input Output
Cabinet
volume
Voltage (V)
Rated current
(A)
Power
(kW)
Rated
current (A)
SV-DA200-0R1-2 Single/Three phase 220 0.9/0.4 0.1 1.3 A
SV-DA200-0R2-2 Single/Three phase 220 1.8/0.8 0.2 1.8 A
SV-DA200-0R4-2 Single/Three phase 220 3.6/1.5 0.4 2.8 A
SV-DA200-0R7-2 Single/Three phase 220 6.8/2.8 0.75 4.5 B
SV-DA200-1R0-2 Single/Three phase 220 9.1/3.7 1.0 5 B
SV-DA200-1R5-2 Three phase 220 5.6 1.5 7.6 B
SV-DA200-2R0-2 Three phase 220 7.5 2.0 10 D
SV-DA200-3R0-2 Three phase 220 11.2 3.0 13 D
SV-DA200-4R4-2 Three phase 220 16.5 4.4 16.5 D
SV-DA200-1R0-4 Three phase 400 2.1 1.0 3.5 B
SV-DA200-1R5-4 Three phase 400 3.1 1.5 4.5 B
SV-DA200-2R0-4 Three phase 400 4.1 2.0 6.5 C
SV-DA200-3R0-4 Three phase 400 6.2 3.0 8.5 C
SV-DA200-4R4-4 Three phase 400 9.1 4.4 12 D
SV-DA200-5R5-4 Three phase 400 11.3 5.5 16 D
SV-DA200-7R5-4 Three phase 400 15.5 7.5 25 F
SV-DA200-011-4 Three phase 400 22.7 11 33 F
SV-DA200-015-4 Three phase 400 31 15 50 F2
SV-DA200-022-4 Three phase 400 45.4 22 66 G
1.2 Servo motor
1.2.1 Nameplate of the motor
S/N:
INPUT:
AC 3PH 220V 2.8A
OUTPUT(RATED): 400W 3000r/min 1.3N·m
IP65 S1 CLASS F NO.3010004(236)
MADE IN CHINA
INVT INDUSTRIAL TECHNOLOGY CO.,LTD.
MODEL: SV-ML06-0R4G-2-4A0-3000
