INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Product overview
‐7‐
1.3 Cables
1.3.1 Nameplate of cables
67002-00351
MADE IN CHINA
5m power flexible towline cable
， 0.75mm cable
diameter
， 4PIN plastic piug ， 7PIN 20A plug
DAML-075-05-ABF-00
R
INVT INDUSTRIAL TECHNOLOGY(SHANGHAI)CO.,LTD.
上海英威腾工业技术有限公司
2
1.3.2 Naming of the power cables
Symbol Instruction Naming instance
① Product series For internal use by manufacturer
② Power cable ML: Power cable
③ Cable diameter
075: 0.75mm
2
100: 1.0mm
2
150: 1.5mm
2
250: 2.5mm
2
400: 4.0mm
2
600: 6.0mm
2
10R: 10mm
2
16R: 16mm
2
25R: 25mm
2
④ Cable length
03: 3m
05: 5m
10: 10m
……
⑤ Plug on motor end
A: 4PIN plastic plug
B: 4PIN regular aviation plug YD28
