SV-DA200 series AC servo drives Product overview
‐5‐
Note: “No. 3010004” in the nameplate is the motor model code (motor code for short). Please input
this code into servo parameter P0.00 correctly (P0.00 is long parameter which can be set via keypad.
See details at chapter 5.2.1 (8), otherwise, the servo system may not operate normally and major
fault may occur to the drive and motor.
1.2.2 Naming of the servo motor
Symbol Instruction Naming instance
①
Product
category
SV: Servo system product
②
Product
series
M: M series
C: C series
S: S series
③ Inertial class
L: Small inertia general servo motor
M: Medium inertia general servo motor
H: Large inertia general servo motor
④ Base no.
04: 40mm
(2)
06: 60mm
08: 80mm
11: 110mm
13: 130mm
18: 180mm
20: 200mm
26: 263mm
⑤ Rated power
0R1: 100W
0R2: 200W
0R4: 400W
0R7: 750W
0R8: 800W/850W
1R0: 1.0kW
1R2: 1.2Kw
1R3: 1.3kW
1R5: 1.5kW
1R8: 1.8kW
2R0: 2.0kW
3R0: 3.0kW
4R4: 4.4kW
5R5: 5.5kW
