Figure 21
Figure 22
12 34 5
MIN. DIA.
MAX. DIA.
MIN. DIA.
MAX. DIA.
1234
MAIN JOURNALS
Table for entering
main journal and
crankpin
measurements
CRANKPINS
The engine shaft is nitrided and its grinding is not
foreseen
105.000
104.980
121.995
121.975
CRANKSHAFT JOURNAL DATA
Check the state of the main journals and crankpins of the crankshaft. They must show no sign of scoring, ovality or excessive
wear. The data given refer to the nominal pin diameter.
8821
37710
NOTE
SECTION 4 - OVERHAUL AND TECHNICAL SPECIFICATIONS 17
VECTOR 8 ENGINES
Print P2D32V001E Base - April 2006
