− 14 −
1) Open hook cover q.
2) Raise latch e of bobbin case w, and remove the
bobbin case.
3) When installing the bobbin case, fully insert it into
the shuttle shaft, and close the latch.
If it is not fully inserted, bobbin case w
may slip off during sewing.
3. Threading the machine head
Pull out the thread by approximately 4 cm from the needle after threading through the needle.
1. When the silicon oil is used, thread through thread guide for silicon q (Optional)
2. For thick thread, pass the thread through one hole only of needle bar thread guide w.
4. Installing and removing the bobbin case
q
w
e
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
q
w
Thin synthetic thread or the like
To Next Page
