− 24 −
[6] OPERATION OF THE SEWING MACHINE (ADVANCED)
1. Performing sewing using the pattern keys ( , , , and )
Patterns (No.1 to 200) which have been already registered can be registered to P1 to P50. It is possible to
change and register the scale, max. speed limitation, thread tension and sewing position. Same as the
patterns (No.1 to 200), P1 to P50 are used by the selection by scrolling the pattern Nos. The pattern calling
from P1 to P25 can be made by one-touch as well.
* When selecting P6 to P25, perform the selection by combination (simultaneous pressing) of , ,
, and keys as shown in the table below.
P-No. Selection key P-No. Selection key P-No. Selection key P-No. Selection key
P1 P1 P8 P1+P4 P15 P4+P5 P22 P2+P3+P4
P2 P2 P9 P1+P5 P16 P1+P2+P3 P23 P2+P3+P5
P3 P3 P10 P2+P3 P17 P1+P2+P4 P24 P2+P4+P5
P4 P4 P11 P2+P4 P18 P1+P2+P5 P25 P3+P4+P5
P5 P5 P12 P2+P5 P19 P1+P3+P4
P6 P1+P2 P13 P3+P4 P20 P1+P3+P5
P7 P1+P3 P14 P3+P5 P21 P1+P4+P5
(1) Register to the pattern key
Setting example : Register following setting to the P2., Pattern No. 3, X scale rate : 50%, Y Scale rate : 80%,
Max. speed limitation : 2,000 rpm, Thread tension : "50", Pattern position : 0.5 mm to the
right and 1 mm to the front
1) Turn ON the power switch and press key
to enter mode setting (memory switch setting).
(Sewing LED should be put out.)
2) Indicate the pattern register mode with
or key.
3) Press key.
Enter the pattern register mode.
4) Press key. (Select P-No. to be registered.)
Selection can be performed with or
key.
5) Press key to indicate the Pattern No .
Set the Pattern No. to "3" with or
key.
e
e
e
e
e
–
To Next Page
