− 21 −
5. Winding a bobbin
5-1. To wind a bobbin while the sewing machine is performing sewing
Thread the bobbin winder and wind the bobbin thread
onto the bobbin as illustrated in the figure.
5-2. To wind a bobbin independently
1) Press key to make the SEWING LED go
off.
2) Select the bobbin winder with key.
Selection cannot be performed when the
Sewing LED is lit up.
3) Press key. The work clamp feet come down
and the Sewing LED lights up.
4) When the pedal switch is depressed, the sewing
machine rotates.
5) When the pedal is depressed again, or key or
key is pressed, the sewing machine stops.
6) When key is pressed, the Sewing LED goes
off, the work clamp feet go up and key
becomes effective.
Bobbin winder does not work immediately
after turning ON the power. Perform the
bobbin winding after setting pattern No.
or the like once, pressing the key,
and making the sewing LED light up.
d
h
h
h
