TS-990S
206
ADJUSTMENT
Adjustment Points (Upper Side)
■
FINAL UNIT (X45-3880-00) (A/2)
■
AT UNIT (X53-4410-00) (A/2)
CN36
CN32
VR1
VR2
VR3
VR4
FRONT
FINAL UNIT
(X45-3880-00) (A/2)
TP5
TP6
TC1
FRONT
CN24
TP1
(VSR)
CN47
VR1
AT UNIT
(X53-4410-00) (A/2)
TP2
(AMD)
